Ultra-Containment Berm® Rapid Rise Model

Description

Sidewalls stay lowered and out of the way until they are needed

To some, a containment berm’s sidewalls mean security. To others, they are a nuisance.

One of the main advantages of the Ultra-Containment Berm Rapid Rise Model is that the sidewalls stay out of the way until they are needed. Foam in the top, outer perimeter of this containment berm’s sidewalls raise the walls with the level of the liquid and rigid struts provide added support. Walls stay down and flat during normal, day-to-day, operations. Helps comply with SPCC and EPA spill containment regulations.

Product Highlights

  • Sidewalls remain down during normal operations, loading, and unloading. Vehicles and equipment can drive in and out with no set-up or take-down required.
  • In the case of a spill, the foam ring around the top perimeter of the containment berm rises with the level of spilled liquid.
  • Built-in struts around the perimeter of the berm provide additional support when the liquid level is high.
  • Provides quick and easy spill containment for drums, IBCs, vehicles, frac tanks and other large containers.
  • Built-in handles help with transport and placement.
  • Material of construction: Copolymer-2000™.
  • Custom sizes available.

Additional Information

  • Operating temperature: Copolymer-2000:  Max 160°F, Min:  -25°F
  • PVC:  Max 150°F, Min:  -20°F
  • Material weights: Copolymer 2000 – 25 oz. / sq. yard; PVC – 22 oz. / sq. yard
  • We can make containment berms in custom sizes in virtually any length and width.
  • Custom heights are available for most of the Ultra-Containment Berms. Please contact us for more information.
  • Ultra-Containment Berms ship at class 125.

Ultra-Containment Berms - Rapid-Rise Models - Copolymer 2000™

Dimensions ft. (m) Containment Capacity gal. (L) Weight lbs. (kg)
6 x 4 x 1 (1.8 x 1.2 x .3) 179 (677.6) 29 (13.2)
6 x 6 x 1 (1.8 x 1.8 x .3) 269 (1018.3) 35 (15.9)
10 x 10 x 1 (3 x 3 x .3) 748 (2831.5) 63 (28.6)
12 x 12 x 1 (3.7 x 3.7 x .3) 1077 (4076.9) 85 (38.6)
26 x 12 x 1 (7.9 x 3.7 x .3) 2333 (8831.4) 149 (67.6)
30 x 12 x 1 (9.1 x 3.7 x .3) 2692 (10190.3) 171 (77.6)
40 x 12 x 1 (12.2 x 3.7 x .3) 3590 (13589.6) 218 (98.9)
50 x 12 x 1 (15.2 x 3.7 x .3) 4488 (16988.9) 266 (120.7)
60 x 12 x 1 (18.3 x 3.7 x .3) 5385 (20384.4) 313 (142)
72 x 12 x 1 (21.9 x 3.7 x .3) 6462 (24461.3) 370 (167.8)
15 x 15 x 1 (4.6 x 4.6 x .3) 1683 (6370.8) 115 (52.2)
20 x 15 x 1 (6.1 x 4.6 x .3) 2244 (8494.5) 141 (64)
30 x 15 x 1 (9.1 x 4.6 x .3) 3366 (12741.7) 195 (88.5)
40 x 15 x 1 (12.2 x 4.6 x .3) 4488 (16988.9) 248 (112.5)
50 x 15 x 1 (15.2 x 4.6 x .3) 5610 (21236.2) 278 (126.1)
60 x 15 x 1 (18.3 x 4.6 x .3) 6732 (25483.4) 356 (161.5)
66 x 15 x 1 (20.1 x 4.6 x .3) 7405 (28031) 357 (161.9)
72 x 15 x 1 (21.9 x 4.6 x .3) 8078 (30578.6) 420 (190.5)


Ultra-Containment Berms - Rapid-Rise Models - PVC 22 oz.

Dimensions ft. (m) Containment Capacity gal. (L) Weight lbs. (kg)
6 x 4 x 1 (1.8 x 1.2 x .3) 179 (677.6) 24 (10.9)
6 x 6 x 1 (1.8 x 1.8 x .3) 269 (1018.3) 34 (15.4)
10 x 10 x 1 (3 x 3 x .3) 748 (2831.5) 57 (25.9)
12 x 12 x 1 (3.7 x 3.7 x .3) 1077 (4076.9) 66 (29.9)
26 x 12 x 1 (7.9 x 3.7 x .3) 2333 (8831.4) 118 (53.5)
30 x 12 x 1 (9.1 x 3.7 x .3) 2692 (10190.3) 210 (95.3)
40 x 12 x 1 (12.2 x 3.7 x .3) 3590 (13589.6) 170 (77.1)
50 x 12 x 1 (15.2 x 3.7 x .3) 4488 (16988.9) 265 (120.2)
60 x 12 x 1 (18.3 x 3.7 x .3) 5385 (20384.4) 244 (110.7)
72 x 12 x 1 (21.9 x 3.7 x .3) 6462 (24461.3) 288 (130.6)
15 x 15 x 1 (4.6 x 4.6 x .3) 1683 (6370.8) 93 (42.2)
20 x 15 x 1 (6.1 x 4.6 x .3) 2244 (8494.5) 114 (51.7)
30 x 15 x 1 (9.1 x 4.6 x .3) 3366 (12741.7) 158 (71.7)
40 x 15 x 1 (12.2 x 4.6 x .3) 4488 (16988.9) 201 (91.2)
50 x 15 x 1 (15.2 x 4.6 x .3) 5610 (21236.2) 244 (110.7)
60 x 15 x 1 (18.3 x 4.6 x .3) 6732 (25483.4) 286 (129.7)
66 x 15 x 1 (20.1 x 4.6 x .3) 7405 (28031) 313 (142)
72 x 15 x 1 (21.9 x 4.6 x .3) 8078 (30578.6) 338 (153.3)



WARNING: All part numbers on this page can expose you to chemicals including Di(2-ethylhexyl) phthalate (DEHP) which is known to the state of California to cause cancer, birth defects, or reproductive harm. For more information, please visit www.P65Warnings.ca.gov
